Description
| OS | Windows / iOS / Android / Linux |
|---|---|
| Image Sensor | CMOS |
| Pixel | 640×480 |
| Reading Precision | =3mil |
| Reading Depth of Field | EAN13 (13mil): 55mm–300mm QR CODE (15mil): 35mm–190mm |
| Lighting | White LED |
| Focusing | Red light LED 625nm |
| Dimensions | 16cm × 9.5cm × 7.1cm |
| Communication Port | USB 2.0 TypeA male connector |
| Barcode Sensitivity | Inclined ±50° / rotary 360° / deflected ±50° |
| Field of View Angle | Horizontal 45°, vertical 34° |
| Power Adapter | Operating voltage: DC5V ±5% Operating current: <500mA |
| Symbol Contrast | ≥30% |
| Prompt | Buzzer, vibrator LED prompt |
| Environment | Operating temperature: -10°C ~ 50°C Storage temperature: -40°C ~ 70°C Relative humidity: 5% ~ 95% (no condensation) Electrostatic protection: ±8kV (direct discharge), ±15kV (air discharge) Drop height: 1.2 meters |
| Symbologies | 1D: Code128, UCC/EAN-128, AIM128, EAN-8, EAN-13, ISBN/ISSN, UPC-E, UPC-A, Interleaved 2 of 5, ITF-6, ITF-4, Matrix 2 of 5, Industrial 25, Standard 25, Code39, Codabar, Code 93, Code 11, Plessey, MSI-Plessey, RSS-14, RSS-Limited, RSS-Expand 2D: PDF417, QR Code, Data Matrix |
